ADV200 • Functions description and parameters list 81
If set to 0 all the motor parameters are measured except those relating to the non-linear saturation curve. Use
this mode to obtain a faster self-tuning procedure.
If set to 1 all the motor parameters are measured. Use this mode to obtain maximum efciency: this procedure
may take a few minutes.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.12 2028 Take par status ENUM Required 0 0 R FVS
Indication of the status of parameter saving.
0 Required
1 Done
The parameter displays the Required message when the motor parameters that have been entered need to be
saved. When they have been saved the parameter indicates Done.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.13 2030 Autotune status ENUM Required 0 0 R FVS
Indication of the status of execution of motor parameter self-tuning.
0 Required
1 Done
The parameter displays the Required message when motor parameter self-tuning is required. When self-tuning
is complete the parameter indicates Done.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.14 2050 Measured Rs ohm FLOAT CALCF 0.0005 200.0 ERWS FVS
Measured stator resistance value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.15 2052 Measured DTL V FLOAT 0.0 0.0 100.0 ERWS FVS
Measured value of dead time compensation.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.16 2054 Measured DTS V/A FLOAT 0.0 0.0 100.0 ERWS FVS
Measured compensation gradient value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.17 2056 Measured Lsig mH FLOAT CALCF 0.01 700.0 ERWS FVS
Measured leakage inductance value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.18 2058 Measured ImN A FLOAT CALCF 0.1 1000.0 ERWS FVS
Measured rated magnetizing current value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.19 2060 Measured ImX A FLOAT CALCF 0.0 0.0 ERWS FVS
Measured magnetizing current saturation value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.20 2062 Measured FlxN Wb FLOAT CALCF 0.05 10.0 ERWS FVS
Measured rated ux value.
