• Parametri del dispositivo - Indici primari
Index Sub-index
Name of the
object
Access
Length
Data
type
Value
(example)
Range of
values
Scale
factor
Offset Unit Description
U M S
0x0040 0x00 Hb.E
RO R/W R/W 2
UInt16 1 (default)
0, 1 1 0 -
Enabling HB alarm
0x0041 0x00 Hb.m
RO R/W R/W 2
UInt16 0 (default)
0, 1 1 0 -
Enable memory for
HB alarm
0x0042 0x00 Hb.F
RO R/W R/W 2
UInt16 0 (default)
0, 1, 2 1 0 -
HB alarm function
0x0043 0x00 A.Hb
RO R/W R/W 2
UInt16 0 (default)
L.tA…H.tA 0.1 0 A
HB alarm threshold
0x0044 0x00 Hb.t
RO R/W R/W 2
UInt16 10 (default)
0…999 1 0 s
Delay time for HB
alarm activation
0x0045 0x00 Hb.P
RO R/W R/W 2
UInt16 90.0 (default)
0.0…100.0 1 0 %
HB alarm threshold
percentage
0x0046 0x00 Hb.tA
RO R/W R/W 2
UInt16 0 (default)
L.tA…H.tA 0.1 0 A
Current reading in HB
calibration
0x0047 0x00 Hb.tV
RO R/W R/W 2
UInt16 0 (default)
L.tV…H.tV 0.1 0 V
Voltage reading in HB
calibration
0x0048 0x00 Hb.Pw
RO R/W R/W 2
UInt16 0 (default)
0.0…100.0 1 0 %
Power read in HB
calibration
0x0049 0x00 hd.5
RO R/W R/W 2
UInt16 1 (default)
0, 1, 2, 3 1 0 -
Trigger modes
0x004A 0x00 bF.Cy
RO R/W R/W 2
UInt16 1 (default)
1…10 1 0 -
Minimum number of
Burst Firing cycles
0x004B 0x00 PS.E
RO R/W R/W 2
UInt16 0 (default)
0, 1, 2, 3 1 0 -
Softstart ramp
enabling.
0x004C 0x00 PS.tm
RO R/W R/W 2
UInt16 10.0 (default)
0.1…60.0 0.1 0 s
Soft start ramp
duration
0x004D 0x00 PS.oF
RO R/W R/W 2
UInt16 2 (default)
0…999 1 0 s
Soft start ramp
reactivation time
0x004E 0x00 FA.P
RO R/W R/W 2
UInt16 0.0 (default)
0.0…100.0 0.1 0 %
Fault Action Power
0x004F 0x00 tyP
RO R/W R/W 2
UInt16 1 (default)
0, 1, 2, 3, 4,
5, 6
1 0 -
Analog input type (*)
0x0050 0x00 Lo.S
RO R/W R/W 2
Int16 0 (default)
-100.0…
200.0
0.1 0 -
Analog input scale
minimum limit (*)
0x0051 0x00 HI.S
RO R/W R/W 2
Int16
1000
(default)
Lo.S…200.0 1 0 -
Analog input scale
maximum limit (*)
0x0052 0x00 FLt
RO R/W R/W 2
UInt16 0.1 (default)
0.0…20.0 0.1 0 s
Analog input signal
digital low-pass lter (*)
0x0053 0x00 F.tA
RO R/W R/W 2
UInt16 0.1 (default)
0.0…20.0 0.1 0 s
Current reading low
pass digital lter
0x0054 0x00 F.tV
RO R/W R/W 2
UInt16 2.0 (default)
0.0…20.0 0.1 0 s
Voltage reading low
pass digital lter
0x0055 0x00 oFS
RO R/W R/W 2
UInt16 0 (default)
0.0…99.9 0.1 0 -
Analog input
correction offset
0x0056 0x00 o.tA
RO R/W R/W 2
UInt16 0 (default)
0.0…99.9 0.1 0 A
Current reading
correction offset
0x0057 0x00 o.tV
RO R/W R/W 2
UInt16 0 (default)
0.0…99.9 0.1 0 V
Voltage reading
correction offset
0x005B 0x00 o.19
RO R/W R/W 2
UInt16 36 (default)
0, 1 1 0 -
Reference for output
pin 19 (*)
0x005C 0x00 Ct
RO R/W R/W 2
UInt16 2.0 (default)
0.1…30.0 0.1 0 s
SSR output cycle time
0x005D 0x00 hd.2
RO R/W R/W 2
UInt16 7 (default)
0, 1, 2, 3, 4,
5, 6, 7
1 0 -
Enabling Power Fault
alarms
0x005E 0x00 PF.m
RO R/W R/W 2
UInt16 0 (default)
0, 1 1 0 -
Enable memory for
Power Fault alarms
0x005F 0x00 dG.t
RO R/W R/W 2
UInt16 10 (default)
1…999 1 0 s
SSR_SHORT update
time
0x0060 0x00 dG.F
RO R/W R/W 2
UInt16 10 (default)
0…99 1 0 s
NO_VOLTAGE and
NO_CURRENT alarm
lter
0x0061 0x00 but
RO R/W R/W 2
UInt16 1 (default)
0, 1 1 0 -
Front key enabling
0x0062 0x00 (*)
0x0063 0x00 i.14 RO R/W R/W 2 UInt16 0 (default)
0, 1, 2, 3, 4,
5, 6
1 0 -
Pin 14 digital input
function
