819XX_MAN_GRM-H_11-2022_ENG_pag. 84
0x0081 0x00 Ir.tV.9 RO R/W R/W 2 UInt16 0 (default) L.tV…H.tV
0.1 0 V
Voltage reading in
HB calibration for IR
lamps
0x0082 0x00 PS.S.E RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
Phase softstart at
ON/OFF software
switching shutdown
0x0083 0x00 Cu.S.E RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
Peak current limiter
during softstart
0x0084 0x00 PS.tA RO R/W R/W 2 UInt16 70.0 (default) 0.0…999.9
0.1 0 A
Maximum peak
current during the
softstart phase
0x0085 0x00 Cu.F.E RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
RMS steady state
current control
0x0086 0x00 Fu.tA RO R/W R/W 2 UInt16 25.0 (default) 0.0…999.9
0.1 0 A
Maximum RMS
current at steady
state
0x0087 0x00 dly.E RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
Enable triggering
delay
0x0088 0x00 dly.t RO R/W R/W 2 UInt16 60 (default) 0…90
1 0 °
Triggering delay
0x0089 0x00 dly.Of RO R/W R/W 2 UInt16 5 (default) 0…10000
1 0 ms
Minimum non-
conduction time to
reactivate triggering
delay
0x008A 0x00 ind.E RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
Inductive load on
0x008B 0x00 hd.6 RO R/W R/W 2 UInt16 0 (default)
0, 1, 2, 3, 4,
5, 6
1 0 -
Feedback mode
conguration
0x008C 0x00 rIF.V RO R/W R/W 2 UInt16 0.0 (default) 0.0…999.9
0.1 0 V
Voltage feedback
reference
0x008D 0x00 rIF.A RO R/W R/W 2 UInt16 0.0 (default) 0.0…999.9
0.1 0 A
Current feedback
reference
0x008E 0x00 rIF.P RO R/W R/W 2 UInt16 0.00 (default) 0.00…150.00
0.01 0 kW
Power feedback
reference
0x008F 0x00 rIF.I RO R/W R/W 2 UInt16 0.00 (default) 0.00…650.00
0.01 0 ohm
Impedance
feedback reference
0x0090 0x00 (*)
0x0091 0x00 Fb.It RO R/W R/W 2 UInt16 0.3 (default) 0.1…5.0
0.1 0 %/60ms
Feedback response
speed
0x0092 0x00 Lo.P RO R/W R/W 2 UInt16 0.0 (default) 0.0…50.0
0.1 0 %
Minimum trigger
output power
0x0093 0x00 P.On.t RO R/W R/W 2 UInt16 0 (default) 0, 1, 2
1 0 -
Start modes (*)
0x0094 0x00 G.Out RO R/W R/W 2 UInt16 0.0 (default) 0.0…200.0
0.1 0 %/s
Power output
gradient
0x0095 0x00 Man.L RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
Manual power
storage (*)
0x0096 0x00 Fr.n RO R/W R/W 2 UInt16 0 (default) 0…20
1 0
Number of
restarts in case of
SHORT_CIRCUIT_
CURRENT
0x0097 0x00 C.E.m RO R/W R/W 2 UInt16 0 (default) 0, 1, 2
1 0 -
Communication
error mode
0x0098 0x00 C.E.t RO R/W R/W 2 UInt16 0 (default) 0…999
1 0 s
Communication
error timeout
0x0099 0x00 C.E.P RO R/W R/W 2 UInt16 0.0 (default) 0.0…100.0
0.1 0 %
Output power with
communication error
0x009A 0x00 Hb.Pm RO R/W R/W 2 UInt16
100.0
(default)
0.0…100.0
0.1 0 %
Maximum power
during HB
calibration (for IR
lamps only)
0x009B 0x00 PWM.t RO R/W R/W 2 UInt16 1.00 (default) 0.01…10.00
0.01 0 s
PWM input timeout
0x009C 0x00 PWM.F RO R/W R/W 2 UInt16 0.1 (default) 0.0…20.0
0.1 0 s
Digital lter for
PWM input
0x009D 0x00 o.19.t RO R/W R/W 2 UInt16 0 (default) 0, 1
1 0 -
Pin 19 output type
(*) settings for future developments
