Index Sub-index
Name of the
object
Access
Length
Data
type
Value
(example)
Range of
values
Scale
factor
Offset Unit Description
U M S
Index Sub-index
Name of the
object
RO RO RO Length
Data
type
Value
(example)
Range of
values
Scale
factor
Offset Unit
Number of hours of
SSR operation
0x00B6 0x00
Ntc.SSR.
Max1
RO RO RO 2 Uint16 0
0…65535
1 0
°C
Max temperature
value reached 1
0x00B7 0x00
Ntc.SSR.
Max2
RO RO RO 2 Uint16 0
0…65535
1 0
°C
Max temperature
value reached 2
0x00B8 0x00 Ld.E1
RO RO RO 2 Uint16 0
0…65535
0.01 0 kWh
Consumed energy
meter 1
0x00B9 0x00 Ld.E2
RO RO RO 2 Uint16 0
0…65535
0.01 0 kWh
Consumed energy
meter 2
0x00BA 0x00 Hb.c1
RO RO RO 2 Uint16 0
0…65535
1 0 -
HB alarms counter 1
0x00BB 0x00 Hb.c2
RO RO RO 2 Uint16 0
0…65535
1 0 -
HB alarms counter 2
0x00BC 0x00 SH.c1
RO RO RO 2 Uint16 0
0…65535
1 0 -
Overheat event
counter 1
0x00BD 0x00 SH.c2
RO RO RO 2 Uint16 0
0…65535
1 0 -
Overheat event
counter 2
0x00BE 0x00 FO.c1 RO RO RO 2 Uint16 0 0…65535 1 0 -
SHORT_CIRCUIT_
CURRENT event
counter 1
0x00BF 0x00 FO.c2 RO RO RO 2 Uint16 0 0…65535 1 0 -
SHORT_CIRCUIT_
CURRENT event
counter 2
0x0100 0x00 Hb.tr
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 A
Current HB alarm
threshold
0x0101 0x00 ALSTATE_HB
RO RO RO 2 Uint16 0
0…65535
1 0 -
Detailed HB alarm
status
0x0102 0x00 INPUT_DIG
RO RO RO 2 Uint16 0
0…65535
1 0 -
Digital input status
0x0103 0x00 MASKOUT
RO RO RO 2 Uint16 0
0…65535
1 0 -
Status outputs
0x0104 0x00 FrEq
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 Hz
Mains voltage
frequency
0x0105 0x00
FAD_
SELECT1
RO RO RO 2 Uint16 0
0…65535
1 0 - Recognition 1
0x0106 0x00
FAD_
SELECT2
RO RO RO 2 Uint16 0
0…65535
1 0 - Recognition 2
0x0107 0x00 FAD_NTC
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x0108 0x00 FAD_PV
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x0109 0x00 FAD_TA
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x010A 0x00 FAD_TV
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x010B 0x00 Ntc.SSR
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0
°C
SSR temperature
0x010C 0x00 Ntc.SSr.der
RO RO RO 2 Int16
0.0
-32768…
32767
0.1 0 °C/12s
SSR temperature
derivative
0x010D 0x00 P. V.
RO RO RO 2 Uint16 0
0…65535
0.1 0 -
Analog input value
(process variable)
0x010E 0x00 Errr
RO RO
RO 2 Uint16 0
0…65535
1 0 -
Analog input status
0x010F 0x00 I.tA
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 A
Real-time current
reading input value
0x0110 0x00 I.tV
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 V
Voltage reading input
real-time value
0x0111 0x00 STATUS2
RO RO RO 2 Uint16 0
0…65535
1 0 -
Alarm states
0x0112 0x00 STATUS3
RO RO RO 2 Uint16 0
0…65535
1 0 -
Status
0x0113 0x00 TA_OFFSET
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x0114 0x00
Inta_adc_
peak
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x0115 0x00 I.tAP
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 A
0x0116 0x00 I.onADC
RO RO RO 2 Uint16 0
0…65535
1 0 -
0x0117 0x00 I.onF
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 A
Current reading input
value
0x0118 0x00
IN_TA_ON_
DIAG
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 A
0x0119 0x00
IN_TA_OFF_
DIAG
RO RO RO 2 Uint16 0.0
0.0…6553.5
0.1 0 A
