8.6.3 Analogue output
Note: The analogue output 4-20 mA must be ordered using the ordering option "Option".
Actual value output: 0 - 10 V
4 - 20 mA (optional)
Output type: Active
On-load current: 0–10 V: Max. 10 mA
Load resistor: 4 – 20 mA:
max. 600 Ω (for ordering option "Option" code 2, 3, 4, 7)
Accuracy/linearity: ≤ ±1% of full flow
Temperature drift: ≤ ±0.5% of full flow
Resolution: 12 bit
Short-circuit proof: Yes
Overload proof: Yes (up to ± 24 V DC)
8.6.4 Digital output signals
Switching outputs: Alarm output 1
Alarm output 2
Error message output
Switching voltage: Supply voltage
Drop voltage: Max. 2.5 V DC at 0.5 A
Short-circuit proof: yes
Overload proof: Yes (up to ± 24 V DC)
Type of contact: PNP
Pull-Down resistance: 120 kΩ
On-load current: max. 0.5 A
8.6.5 Travel sensor input
Supply
voltage UP+:
Typically 10 V DC
Resistance range of re-
mote potentiometers:
1 to 10 kΩ
Input voltage
range:
0 to U
P+
Input resistance: 330 kΩ
Accuracy/linearity: ≤ ±0.3% of full flow
Temperature drift: ≤ ±0.3% of full flow
Resolution: 12 bit
