www.gemu-group.com34 / 71GEMÜ 1435 ePos
16 System mode CLASSIC
Display Function Value range Unit Default setting
30:FREE 0%
31:FREE 10%
32:FREE 20%
33:FREE 30%
34:FREE 40%
35:FREE 50%
36:FREE 60%
37:FREE 70%
38:FREE 80%
39:FREE 90%
40:FREE 100%
Definition of the freely program-
mable characteristic curve
11 calibration points
0...100 % 2
3
4.4
6.5
9.6
14.1
20.9
30.9
45.7
67.6
100
42:DEADBAND Size of dead band auto
0.0...10.0
% 1.0%,
K-no. 2442: 2.0%
K-no. 2443: 5.0%
43:PROP GAIN
1)
Proportional amplification (PD
controller)
Kp = 0.1...100.0 1.0
44:DERIV TIME Differential time constant (PD con-
troller)
Tv = 0.00 s...10.00 s s 0.1
45:FIELDBUS SETP.ANALOG FIELDBUS SETP.ANALOG
46:RELEASE VXX Software release V X.X.X.X
50:SYSTEMMODE Defines the type of operator inter-
face
CLASSIC
ADVANCED
CLASSIC
1) Parameter value is automatically calculated and set by the positioner during initialisation. A manual change may have to be repeated after
each initialisation process
