Automation module E0, combi switchbox
Electrical data
Power supply
Power supply U
v
U
v
= 24 V DC ±10 %
Current consumption I
typ
= 40 mA (at 24 V DC)
Reverse battery protection yes
Electrical connection
Electrical connection M12 5-pin plug (A-coded)
Automation module B2, combi switchbox with AS-Interface
Electrical data
Power supply
Power supply U
v
26.5 to 31.6 V DC acc. to AS-Interface specification
Current consumption max. 120 mA
Duty cycle continuous duty
Reverse battery protection yes
Electrical connection
Electrical connection M12 5-pin plug (A-coded)
AS-Interface profile
AS-Interface specification 3.0; max. 62 slaves
AS-Interface profile S 7.A.E
I/O configuration 7
ID code A
ID2 code E
Approvals
AS-Interface certificate Certificate no.: 65202
Electrical data
Power supply
Power supply U
v
U
v
= 24 V DC +10 % / -5 %
Current consumption I
typ
= 70 mA (at 24 V DC)
Analogue input
Accuracy ≤ 0.3 %
Set value input 4-20 mA
Digital input
Initialisation input
Voltage U
rated
= 24 V DC
Level "logical 1" 14 V DC ≤ U
H
≤ 28 V DC
Level "logical 0" 0 V DC ≤ U
L
≤ 8 V DC
Input current I
typ
= 2.5 mA (at 24 V DC)
Electrical connection
Electrical connection M12 5-pin plug (A-coded)
Positioner data
System deviation ≤ 1 %
Initialisation Automatic via 24 V DC signal
Display elements
Status display 4 visible LEDs
Analogue output (automation module F1)
Accuracy / Linearity ≤ ± 1.0 % of full flow
Temperature drift ≤ ± 0.5 % of full flow
Resolution 12 bit
Actual value output 4-20 mA
Output type active
Automation module F0 / F1, positioner
