41 / 68
651
6 Order data (2/2-way valves)
Body con guration Code
Tank bottom valve body B**
2/2-way body D
Multi-port design M**
T body T*
* For dimensions see T Valves brochure
** Dimensions and versions on request
Connection Code
Butt weld spigots
Spigots DIN 0
Spigots DIN 11850, series 1 16
Spigots DIN 11850, series 2 17
Spigots DIN 11850, series 3 18
Spigots DIN 11866, series A 1A
Spigots DIN 11866, series B 1B
Spigots JIS-G 3447 35
Spigots JIS-G 3459 36
Spigots SMS 3008 37
Spigots BS 4825, Part 1 55
Spigots ASME BPE 59
Spigots EN ISO 1127 60
Spigots ANSI/ASME B36.19N, Schedule 10s 63
Spigots ANSI/ASME B36.19N, Schedule 40s 65
Threaded connections
Threaded sockets DIN ISO 228 1
Threaded spigots to DIN 11851 6
One side threaded spigot to DIN 11851,
other side cone spigot with union nut
to DIN 11851 62
Aseptic unions on request
Clamp connections
Clamps ASME BPE for pipe ASME BPE,
length ASME BPE 80
Clamps DIN 32676 series B for pipe EN ISO 1127,
length EN 558, series 7 82
Clamps ASME BPE for pipe ASME BPE,
length EN 558, series 7 88
Clamps DIN 32676 series A for pipe DIN 11850,
length EN 558, series 7 8A
Clamps SMS 3017 for pipe SMS 3008,
length EN 558, series 7 8E
For overview of available valve bodies see data sheet page 12
Automation module Code
Combi switchbox with integrated
pilot valve and status LED E0
Combi switchbox with integrated pilot valve,
OPEN / CLOSED position feedback and Speed
-AP
function, AS-Interface, 62 slaves, Spec. 3.0 B2
Positioner with Speed
-AP
function,
set value input 4-20 mA F0
Positioner with Speed
-AP
function,
set value input 4-20 mA
actual value output 4-20 mA F1
Control function Code
Normally closed (NC) 1
Normally open (NO) 2
Actuator size Code
Actuator size 0 (Diaphragm size 8) 0
Actuator size 1 (Diaphragm size 10) 1
Actuator size 2 (Diaphragm size 25) 2
Design (actuator) Code
Connection in flow direction T
Connection 90° to flow direction R
Spring set Code
Diaphragm size 8 C.f. 1 A
Diaphragm size 8 C.f. 2 1
Diaphragm size 10 C.f. 1+2 1
Diaphragm size 25 C.f. 1+2 1
Diaphragm material Code
EPDM 13 3A*
EPDM 17
PTFE (TFM) / EPDM convex, PTFE (TFM) loose 5E
PTFE (TFM) / EPDM, PTFE (TFM) laminated 52** 5A*
* for diaphragm size 8 ** for diaphragm size 10
Material complies with FDA requirements
Valve body material Code
1.4435 - BN2 (CF3M), investment casting Fe<0.5% 32
1.4435 (ASTM A 351 CF3M 316L), investment casting 34
1.4408, investment casting 37
1.4435 (316 L), forged body 40
1.4435 (BN2), forged body Fe<0.5% 42
1.4539, forged body F4
