34 Owner’s Manual for Power Zone Pro Sync
Troubleshooting
NEED TO SET RTC WN Real time clock needs to be set
ENGINE RELAY INVALID SETTINGS SD Internal relay startup/shutdown control settings
are invalid
RPM1 SENSOR FAIL WN RPM Sensor is not reading valid RPM while the
engine is running, but frequency is present and
valid
RPM1 SENSOR FAIL SD SD RPM Sensor is not reading valid RPM while the
engine is running
VOLTAGE MONITOR FAULT SD Main Controller internal power supply voltage
monitor detected invalid voltage
VREF1 FAULT SD Main Controller internal reference voltage
monitor detected invalid voltage
VREF2 FAULT SD Main Controller internal reference voltage
monitor detected invalid voltage
INVALID AVR SETTINGS SD AVR related settings are invalid and must be
changed
INVALID GOV SETTINGS SD Governor related settings are invalid and must be
changed
ANALOG INPUT DEFINED MULTIPLE TIMES SD Analog input function assigned to multiple analog
input sources
DIGITAL INPUT DEFINED MULTIPLE TIMES SD Digital input function assigned to multiple digital
input sources
BUS VOLTAGE AB NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
BUS VOLTAGE BC NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
BUS VOLTAGE CA NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
BUS VOLTAGE LL NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN CURRENT N NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN VOLTAGE AN NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN VOLTAGE BN NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN VOLTAGE CN NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN VOLTAGE AB NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN VOLTAGE BC NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
Alarm Display Text Type Alarm Description
