Owner’s Manual for Power Zone Pro Sync 35
Troubleshooting
GEN VOLTAGE CA NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN APPARENT PWR LL TOTAL NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GEN REACTIVE PWR LL TOTAL NOT
SETUP
SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
GOVERNOR THROTTLE POSITION 1
NOT SETUP
SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
ESTOP 1 NOT SETUP SD See AI, AO, DI and DO XXX NOT SETUP
Alarms.
J1939 NO MIC3 COMMS SD Lost J1939 CAN bus communications with
MotorTech MIC3+ Ignition Module
J1939 NO VARISTEP COMMS SD Lost J1939 CAN bus communications with
MotorTech Throttle Module
SHUTDOWN BYPASS IS ACTIVE WN Generator protection system is mostly disabled
to provide critical support
SHUTDOWN ALARM IS BYPASSED WN Shutdown condition has occurred while
generator protection system is mostly disabled to
provide critical support
BASELOAD SWITCH STILL OPEN WN Transfer switch open during a baseload
operation
BASELOAD COMMS LOSS WN No Baseload communications within designated
time
NO DUAL FUEL SENSOR SELECTED SD Dual Fuel selected, but no Fuel Pressure Sensor
is setup
PLC PROGRAM x OUTPUT INVALID SD PLC program using invalid output. Can be for
PLC program numbered 1-8.
PLC ESTOP SD PLC program used ESTOP output
PLC PROGRAM x DOF ALREADY USED AL Duplicate DOFs used in multiple PLC programs.
Can be for PLC program numbered 1-8.
INCOMPATIBLE PWM5 CONFIG IN USE BY AVR SD Shutdown condition has occurred as AVR
Excitation Control Output #1 has been configured
by the user as something else
INCOMPATIBLE PWM6 CONFIG IN USE BY AVR SD Shutdown condition has occurred as AVR
Excitation Control Output #2 has been configured
by the user as something else
INVALID DI CONFIGURATION FOR SHUTDOWN
BYPASS
WN Warning condition has occurred as Activate
Shutdown Bypass digital input is not configured
or configured incorrectly
