VT HYBRID 9mt 4x150W LED
31
TL187-01-00-00
01-07-2016
FIAMM battery
40 41 40
13.2.1 AKKUJEN TARKISTUS JA VAIHTO – – CONTROL AND REPLACEMENT BATTERY
…. .
Sijainti
Items
Kuvaus
Description
40
Akkuvaunun lukitustappi
Floodlights blocking rotation pin
41
Akkujen irrotuksen lukituslevy
Locking plate extraction battery
Per effettuare un controllo o per la sostituzione
occorre portare l’interruttore stacca batteria
(37) in posizione OFF.
To check or replace the battery, turn OFF the
pull out switch (37).
Irrota levy (41) paikoiltaan ja vapauta tapit (40).
Irrota akkujen kotelo kuvassa näytetyllä tavalla.
Remove the plate (41) from its position and
unlock the pins (40), then remove the battery
box as shown in the figure.
