Genie DPL Super Series Service Manual

Part No. 40462 DPL25S • DPL-30S • DPL-35S Super Series 2 - 1
Section 2 - SpecificationsSeptember 2016
Specifications
Model DPL-25S DPL-30S DPL-35S
Height, 31 ft 4 in 36 ft 40 ft 9 in
maximum working 9.5 m 11 m 12.4 m
Height, 25 ft 4 in 30 ft 34 ft 9 in
maximum platform 7.7 m 9.2 m 10.6 m
Height, 78 in 78 in 78 in
guard rails stowed 197.8 cm 197.8 cm 197.8 cm
Length, 81
3
/4 in 81
3
/4 in 81
3
/4 in
outriggers stowed 207.6 cm 207.6 cm 207.6 cm
Width, 31
1
/2 in 31
1
/2 in 31
1
/2 in
outriggers stowed 80 cm 80 cm 80 cm
Outrigger footprint 82 x 56
1
/2 in 86
1
/4 x 67
3
/4 in 86
1
/4 x 67
3
/4 in
(l x w) 208.3 x 143.5 cm 218.7 x 172.1 cm 218.7 x 172.1 cm
Platform dimensions 72 x 27
1
/2 in 72 x 27
1
/2 in 72 x 27
1
/2 in
(l x w) 182.9 x 69.9 cm 182.9 x 69.9 cm 182.9 x 69.9 cm
Lift capacity 750 lbs 750 lbs 600 lbs
340 kg 340 kg 272 kg
Power source 12V DC or 12V DC or 12V DC or
220V or 115V AC 220V or 115V AC 220V or 115V AC
Shipping weight 1375 / 1450 lbs 1475 / 1550 lbs 1575 / 1650 lbs
(AC / DC) 624 / 658 kg 669 / 703 kg 714 / 748 kg
Maximum capacity
ANSI 750 lbs / 340 kg 750 lbs / 340 kg 600 lbs / 272 kg
CE 750 lbs / 340 kg 750 lbs / 340 kg 600 lbs / 272 kg
CSA 600 lbs / 272 kg 600 lbs / 272 kg 500 lbs / 227 kg
Ambient operating -20°F to 135°F
temperature -29°C to 57°C
Airborne noise emissions 80 dB
Maximum sound level at normal operating workstations
(A-weighted)
Current Protection Rating
220V AC models 8A fuse, circuit breaker
5A fuse, printed circuit board
110V AC models 15A fuse, circuit breaker
5A fuse, printed circuit board
DC models 175A fuse, power unit
5A fuse, printed circuit board
