4 - 14 DPL-25S • DPL-30S • DPL-35S Super Series Part No. 40462
September 2016
Section 4 - Scheduled Maintenance Procedures
11 Raise and lower the platform through three
complete cycles. Add hydraulic oil if needed to
allow platform to reach full height.
Component Damage Hazard. Do
not allow the hydraulic reservoir to
completely empty when raising the
platform. Pressurized air in the
hydraulic system can damage
hydraulic components.
Hydraulic System
Hydraulic fluid Dexron equivalent
Hydraulic reservoir capacity
AC models 5 quarts 4.7 liters
DC models 5 quarts 4.7 liters
Hydraulic System Capacity (includes reservoir)
AC models
DPL-25S 6 quarts 5.6 liters
DPL-30S 6 quarts 5.6 liters
DPL-35S 6 quarts 5.6 liters
DC models
DPL-25S 6 quarts 5.6 liters
DPL-30S 6 quarts 5.6 liters
DPL-35S 6 quarts 5.6 liters
TABLE C PROCEDURES
C-5
Replacing the Auxiliary Platform
Lowering Batteries
1 Turn the machine off and remove the key.
2 Remove the two ground control box cover
fasteners.
3 Open the base control box and locate the
battery pack inside the base control box.
4 Remove the fasteners that hold the battery pack
in place.
5 Carefully slide the battery pack out of the
holder.
The wires connected to the battery
pack are very small. Be careful not
to damage the wires.
6 Remove the old batteries from the pack.
7 Insert new batteries into the pack.
Make sure the batteries are
installed correctly by following the
diagram on the inside of the
battery pack.
8 Install the battery pack into the ground control
box and tighten the fasteners.
9 Close the ground control box cover and tighten
the fasteners.
To Next Page
