Part No. 404632 DPL-25S • DPL-30S • DPL-35S Super Series 6 - 3
September 2016
Section 6 • Schematics
Hydraulic Legend
Motor
Cylinder
Check Valve
Pump
Filter
Pressure compensated
flow control
Solenoid operated
dump valve
2 position 2 way
directional valve
Adjustable relief valve
