Part No. 40462 DPL-25S • DPL-30S • DPL-35S Super Series 3 - 5
Section 3 - Scheduled Maintenance InspectionsSeptember 2016
Dealer
service
suggested
Tools are
required
New parts
required
Checklist B Y N R
Refer to Table B
B-1 Electrical wiring
B-2 Welds
B-3 Lifting chain
adjustments
B-4 Battery
B-5 Clean and lubricate
columns
B-6 Lifting capacity
B-7 Power to platform
operation
B-8 Sequencing cables
B-9 Proper outrigger
length
Checklist C Y N R
Refer to Table C
C-1 Casters and wheels
C-2 Mast assembly
C-3 Lifting chains
C-4 Hydraulic oil
C-5 Auxiliary platform
lowering batteries
Checklist A Y N R
Refer to Table A
A-1 Operator's
and Responsibility
manuals
A-2 Decals and placards
A-3 Damage, loose or
missing parts
A-4 Hydraulic leaks
A-5 Auxiliary lowering
operation
A-6 Manual lowering
operation
A-7 Battery and charger
- DC models
A-8 Columns
A-9 Sequencing cables
A-10 Interlock system
operation
A-11 Power and
function controls
A-12 Lifting chains
and idler wheels
A-13 Breather cap
Maintenance Inspection Report
Model
Serial number
Date
Machine owner
Inspected by (print)
Inspector signature
Inspector title
Inspector company
Instructions
• Make copies of this page to use for
each inspection.
• Select the appropriate checklist(s) for
the type of inspection to be
performed.
Daily Inspection: A
Quarterly Inspection: A+B
Annual Inspection: A+B+C
• Place a check in the appropriate box
after each inspection procedure is
completed.
• Use the maintenance tables in this
section and the step-by-step
procedures in section 4 to learn how to
perform these inspections.
• If any inspection receives an “N”,
remove the machine from use, repair
and re-inspect it. After repair, place a
check in the “R” box.
Legend
Y = yes, acceptable
N = no, unacceptable
R = repaired
Comments
To Next Page
