Part No. 40462 DPL-25S • DPL-30S • DPL-35S Super Series 5 - 1
September 2016 Section 5 - Troubleshooting Flow Charts
Observe and Obey:
Troubleshooting and repair procedures shall be
completed by a person trained and qualified on
the repair of this machine.
Immediately tag and remove from service a
damaged or malfunctioning machine.
Repair any machine damage or malfunction
before operating the machine.
Before Troubleshooting:
Read, understand and obey the safety rules and
operating instructions printed in the
Genie DPL
Super Series Operator's Manual
.
Be sure that all necessary tools and test
equipment are available and ready for use.
Read each appropiate flow chart thoroughly.
Attempting shortcuts may produce hazardous
conditions.
Be aware of the following hazards and follow
generally accepted safe workshop practices.
Electrocution/burn hazard. Contact
with electrically charged circuits
may result in death or serious
injury. Remove all rings, watches
and other jewelry.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to squirt
or spray.
Perform all troubleshooting on a
firm level surface.
Two persons will be required to
safely perform some
troubleshooting procedures.
