5 - 6 DPL-25S • DPL-30S • DPL-35S Super Series Part No. 40462
September 2016
Section 5 - Troubleshooting Flow Charts
CHART 2
Continued from the
previous page.
Check the voltage on
both sides of the 5amp
P.C. board fuse. Put
Neg. lead of voltage
meter on grounding
terminal 10 of the 13
pole terminal strip (J1).
Replace the 5amp fuse.
If there is voltage on both
sides of the fuse and the
power light is not turned
on, replace P.C. board
OR consult Genie
Industries Service
Department.
12V DC
12V DC
on one
side
