5 - 12 DPL-25S • DPL-30S • DPL-35S Super Series Part No. 40462
September 2016
Section 5 - Troubleshooting Flow Charts
CHART 4
Perform a continuity test
across the motor
contactor coil (terminals 1
and 0).
Replace the motor
contactor.
no
continuity
Check for 110 volts AC
at the common terminals
(white and black wires) of
the motor contactor.
Replace faulty circuit
breaker.
While pushing in the
control activate switch
and activating the up
function, hold both
switches and check for
power at the N.O.
terminals (white and
black wires) on the motor
contactor.
Replace the motor
contactor because of
damaged contacts.
Check the motor wiring
OR consult Genie
Industries Service
Department.
Continued from the
previous page.
continuity
0V AC
110V AC
0V AC
110V AC
To Next Page
