Genie GR-12 Service Manual

Service Manual May 2018
Introduction
iv GR
™
• QS
™
R • QS
™
W Part No. 1275811GT
Serial Number LegendTo August 31, 2016
1 Model
2 Model year
3 Facility code
4 Sequence number
5 Serial label
6 Serial number (stamped on chassis, GR models)
7 Serial number (stamped on chassis, QS models)
From September 1, 2016
1 Model
2 Facility code
3 Sequence number
4 Serial label
5 Serial number (stamped on chassis, GR models)
6 Serial number (stamped on chassis, QS models)

Genie GR-12 Specifications

General

Machine Width	1.2 m
Machine Length	2.44 m
Machine Height	2.54 m
Power Source	Electric
Stowed Height	2.54 m
Drive Speed - Lowered	4.8 km/h
Turning Radius (Inside)	2.44 m
Platform Width	1.12 m
Tire Type	Non-marking
Travel Speed	4.8 km/h
Ground Clearance	0.1 m
Overall Length	2.44 m
Overall Width	1.2 m
Overall Height	2.54 m
