6 7
Number of routes, tracks and markers: unlimited, depend-
ing on the size of the CompactFlash™ used
Interface characteristics
Standard NMEA 0183 sentences
- from position sensor:
GLL, VTG, GGA, RMC, GSV, ZDA, RMA, GSA
- from depth sounder:
DBT, MTW
- to autopilot:
APA, APB, XTE, RMB, BWC, GLL, VTG
CAN protocol, compatible with NMEA 2000
If received from the GPS, the following sentences are trans-
mitted:
GGA, RMC, ZDA.
Accessories
Bracket for detachable installation
Gasket and drilling template for panel mounting
Plastic frame and drilling template for flush mounting (op-
tional on the Sunshine 8 model)
Power supply cable
Auxiliary power supply cable
User and Installation Guide
Protection cap
Carrying case
NOTE: The plotter can be interfaced with instruments featuring the new NMEA 2000
protocol. However, as of the plotter is put on sale, the final issue of the NMEA 2000
standard is not available yet. For this reason, to obtain full efficiency from network
connection, the plotter software may need updating. For further information, consult
your local GEONAV dealer.
Color LCD, TFT 10.4”
Monochrome LCD, STN 9.4”
Color LCD, transflective TFT 10.4”, high brightness, sun-
light visible
Color LCD, TFT 6.4”, sunlight visible
Electrical characteristics
Power supply: 10 to 36 Vd.c.
Power consumption: Max. 13 W
Power consumption: Max. 16 W
Power consumption: Max. 20 W
NMEA 2000 network load: 2
Auxiliary voltage output: 10 to 36 Vd.c.
(same as input voltage) - Max. 250 mA
Protection against: Reverse polarity
Input overvoltage (up to 40 Vd.c.)
Overcurrent at auxiliary voltage out-
put (over 250 mA)
Operating temperature: 0°C to +50°C
Operating temperature: 0°C to +55°C
Storage temperature: -20°C to +60°C
Storage temperature: -20°C to +70°C
Memory characteristics
Up to 100 waypoints per route
Up to 5000 trackpoints (multiple tracks)
Up to 3000 markers per group
Flash
Sun
Sunshine 11
Sunshine 8
Flash
Sun
Sunshine 8
Sunshine 11
Flash
Sun
Sunshine
Sunshine
Flash
Sun
