68
[Special View Setting] Note this function is not available for GV-BX2600.
D/N: Sets the sensitivity of day-night mode switch. The higher the
sensitivity value, the more sensitive the switch is from day mode to
night mode. The default value is 5.
Auto: Select Auto for the camera to detect the amount of light
present and automatically switch to monochrome in a poorly-lit
scene. Move the slider to adjust the sensitivity level from 0 to 10.
Black and White: Select this option for the live view to be in
monochrome.
Color: Select this option for the live view to be in color.
Triggered by Input: For GV-BX12201 firmware V1.02 or later,
select this option to switch between day mode and night mode
once the input device (e.g. sensor or button) is triggered.
Schedule: For GV-BX12201 firmware V1.02 or later, select this
option to determine specific period(s) of time when day mode is
activated. See 4.6.1 Recording Schedule Settings for the details
on the setting of the schedule.
IR Check Function: Note this option is only available for Box
Camera (except GV-BX2600). This function determines whether the
surveillance area is illuminated by an externally installed infrared
illuminator.
Off: The default setting. The infrared illuminator will be constantly
off. It is advisable to enable this option when the color temperature
of outdoor lighting is 6000 K or above.
On: The infrared illuminator will be constantly on.
Trigger by Input / Trigger IR by D/N: Select this option for the
infrared illuminator to turn on under low light and turn off under
sufficient light.
