System Configuration
68
3
[Stream]
Codec: For GV-SNVR0411 / 0412 / 0811 / 0812 / 1611 / 1612, select video codec
between H.264 and H.265. For GV-SNVR0400F / 1600, the video codec is H.264.
Resolution: Select the video resolution for the camera.
FPS: Set up recording frame rate for the camera.
Quality: Select the level of video quality.
Max. Bit Rate: Set up the maximum bit rate of video stream.
Image Orientation: Adjust the image orientation by selecting Normal, Horizontal
Mirror, Vertical Flip or Rotate 180.
Flicker less: The frequency of your camera’s image is automatically matched with the
frequency of indoor light sources, e.g. fluorescent lighting. You can also select 50 Hz or
60 Hz manually. If the frequencies don’t match, faint light or dark bars may appear in
your images. Check the power utility to determine which frequency is used.
[Motion]
Motion Area: Draw up to 8 areas with different sensitivity values on the image for
motion detection.
Motion Sensitivity: Configure the sensitivity value from 1 to 10 for the motion
detection. The higher the value, the more sensitive the camera is to motion.
[System]
Password: Only for GV-SNVR0411 / 0412 / 0811 / 0812 / 1611 / 1612. Change the
password of the camera by typing in a desired password.
To enable adjusted settings, click Apply.
Only for GV-SNVR0411 / 0412 / 0811 / 0812 / 1611 / 1612. To load the camera’s default
settings, click Default.
Note:
1. For the FPS function, GV-SNVR supports up to 30 fps.
2. After loading default, the IP camera will restart and may take some time to reconnect.
3. The Web Page button is intended for configuring the login info of GV-IP cameras
without default ID and password and accessing of third-party camera’s web address.
See 3.1.1.1 Configuring GV-IP Cameras without Default ID and Password.
