Operating Your Tablet PC 2-13
Using the Communication Features
Using the LAN
The internal 10/100/1000Base-T LAN (Local Area Network) module allows
you to connect your tablet PC to a network. It supports data transfer rate
up to 1000 Mbps.
To connect the network cable to the LAN module, connect one end of
the LAN cable to the RJ-45 connector (
) on the tablet PC and the
other end to the network hub.
Using the Wireless LAN
The WLAN features include:
z Peer-to-Peer (Ad-Hoc) and Access Point (Infrastructure) modes
support
z WEP (Wired Equivalent Privacy) 64/128-bit data encryption
z IEEE 802.11b/g standard compliance
Technology 802.11b 802.11g
Stated Maximum
Throughput (Mbps)
11 54
Data Rates (Mbps) 11, 5.5, 2, 1 54, 36, 18, 9
Band (GHz) 2.412 ~ 2.462 2.4
