Getidy JN-23 - Three Pre-Vacuum Sterilization Program Process Schematic

1 Heating coil preheating stage
2 First times pThe re-vacuum stage
3 The First times Heating stage
4 The First times Exhaust stage
5 SThe econd times pre-vacuum stage
10 Start sterilization stage
11 After sterilizationExhaust stage
12 Drying stage
13
record stage
Balance atmospheric and print sterilization
6 The Second times Heating stage
7 SThe econd times Exhaust stage
8 The third times pre-vacuum stage
9 The third times Heating stage
THREE PRE-VACUUM STERILIZATION PROGRAM PROCESS SCHEMATIC
TIME
1 2 3 4 5 6 7 8 9 10 11 12 13
