GFA TS 981 - Page 22

Page 22
Photo beam interrupt
function
Safety functions
CONTROL PROGRAMMING
3. Adjustment
2. Chose program and
conrm
OFF
Selection of external
safety against entrap-
ment devices
NC contact evaluation 1k2 without
testing single
NC contact evaluation 1k2 without
testing double
NO contact evaluation 8k2 single
NO contact evaluation 8k2 double
Impulse-evaluation 1 kHz (Raytector
or OSE) single
Impulse-evaluation 1 kHz (Raytector
or OSE) double
Impulse-evaluation testing signal
(Transmitter – Receiver photo-beam)
single
Impulse-evaluation testing signal
(Transmitter – Receiver photo-beam)
double
Move to RWA position, up to a
minimum height of 2,5 m
RWA smoke draining –
position
OFF
ON
Press
selector
Press
selector
Press STOP-
button
4. Memorise
Slake rope / Pass doorFunction: Door safety
switch
Press
selector
Normal re - open time
This is the reaction time
actuation of the safety
edge up to the moment
that the door re-opens
Re - open time reduction
Re – open time extension
Three adjustment levels available
Press
selector
Crash detector via NC Contact
Crash detector via NO Contact
Impulse-evaluation 1 kHz (optical
safety devices) single;
only STOPP
Impulse-evaluation 1 kHz (optical
safety devices) double;
only STOPP
.2
.0
. 1
3.2
3.4
3.5
3.7
3.8
.0
. 1
. 1
.2
.3
-.-
.3
.4
.5
.6
.7
.8
.9
1.0
_. 1
-.0
-
. 1
