GFA TS 981 - Function Overview

Page 49
FUNCTION OVERVIEW
•
Control panel for ELEKTROMATEN
®
up to. 3 kW at 400 V / 3~ with electronic limit DES
designed for only low-level adjustment
• 7- Segment led display showing
- Programming the control panel
- Displays Command - / Info- / Fault
• Software release loading and saving
• Mains supply
- 400 V / 3~ with and without Neutral
- 230 V / 3~
- 230 V / 1~ (for single-phase motors)
• Door operating modes
- Hold-to-run open- and close
- Self-hold open- and hold-to-run mode close (without safety edge)
- Automatic open- and close (with safety edge connected)
• Integrated safety edge systems
- Electrical safety edge
- Pneumatic safety edge
- Optical safety edge system
• Automatic close feature
- Free programmable from 1 s up to max. 240 s
- On interrupting and re-making light barrier closing after 3 s
- Can be interrupted by a separate switch
• Supply for external devices
- 230 V (at 400 V / 3~ with N), up to 1,6 A load
- 24 V DC, up to 1000 mA load
• Plug for 5 pole motor connector 6 pole for electronic limit DES
• Plug for spiral cable (safety edge and pass-door contact)
• Integrated internal pushbutton OPEN / STOP / CLOSE
• Additional terminals for di󰀨erent control equipment
- Emergency stop (LATCHING)
- Additional safety stops
- External three push button OPEN / STOP / CLOSE
- Light barrier activated Stop and Reverse function, time reset, time interruption 3 s
- One channel - impulse functions e. g. Ceiling pull switch for OPEN / CLOSE / STOP
– sequencing or radio control
- Key switch ( latching) for intermediate Stop
- 2x potential free relay output (NC / NO), output signal from aux. limit
If a signal lamp is in use, the potential free limit is not available
• Integrated tra󰀩c light management
- One-way
- Two-way
