INSTALLATION OVERVIEW
Mains supply
Photo-beam
Pull switch
Three push button
Key switch (latching) interrupt
automatic closing
Emergency stop
Key switch (latching)
intermediate stop
Red / Green Tra󰀩c- Light
Connection cable ELEKTROMAT
®
for
Motor and DES ( electronic limit)
11
5
5
3
5
3
3
3
2x4
Spiral cable for
Safety edge system
4
( )
Number of cores in the cable
Important!
Using the connection cable out side the building is not permitted.
