FUNCTION DESCRIPTION
Internal push button / Three push button / Key switch X5 / X15
Internal and external push button
Internal and external push button working seperately from each other. Pushing at the same
time, the internal push button has priority.
Important note!
Hold-to-run mode UP and DOWN with internal push button.
Hold-to-run mode DOWN with external push button.
(Menu item 0.1 Adjustment „.4“)
In Hold-to-run mode the user shall be in full view of the door throug-
hout its travel.
Automatic closing
Menu item 2.3 the timer works between 1 s - 240 s If the automatic closing is active, the
shutter will close, from each limit position after the pre-adjusted time.
Important note!
The timer can be interrupted by pressing the internal pushbutton stop when
the shutter has reached a limit position. With a new command UP / DOWN
the timer is re-set.
Reaction of automatic closing to photo cell / light curtain
Menu item 2.4 can be used if the timer operation is required after interrupting and re-making
the photo-beam / Light curtain. The door closes after 3 seconds.
Emergency stop X3
Important note!
Frequency inverter drive unit: The emergency stop switches the supply o.
The door control can only be operated again 30 seconds after unlocking the
emergency stop. (Display rotates during this time)
Connection of an emergency stop control device as per EN 13850 or an evaluation unit for
an anti-trap safety device. The F1.4 fault indication appears upon activation.
