Page 39
FUNCTION DESCRIPTION
AIR look SLF
Status monitoring function SMF
Air-lock management could be realised by means an easy electrical cable connection between
two shutters with TS 981.
The required module with cable should be connected into SLF plug-in. This module would
be delivered complete within a manual.
When cable connection is nalized select AIR-LOCK ON in Menu item 7.1 in both control
panels.
Automatic OPEN - Transmission
To realise Air-lock operation a push button is not required. An automatic open impulse about
timer adjustment could be selected in Menu item 7.2, thereafter the present closed shutter
OPENS when acting shutter has CLOSED.
When in use a port supplies status or error information’s to a central monitoring unit. To realise
a lot of dierent uses the control has a socket to be used with external modules that supplies
relay contacts or BUS-gateway.
Users manual would be delivered with the module.
Maintenance cycle counter
Free adjustable maintenance cycle counter Menu item 8.5 makes it possible to pre-adjust a
max. No of cycles until a maintenance is agreed.
The no of cycles can be adjusted from 1.000 up to 99.000; the adjustment is possible in steps
of 1.000 cycles.
Three dierent reactions can be chosen if the point of pre- adjusted maintenance cycles has
been reached, see Menu item 8.6
Whenever the nal open limit has been contacted the pre-adjusted number will be reduced
with 1 until 0 is reached.
When maintenance was done the cycle counter could be re-adjusted to a new maintenance
period and count down starts again.
