TECHNICAL DATA
Housing Dimensions 190 mm x 300 mm x 115 mm (W x H x D)
Mounting vertical
ELEKTROMATEN
®
Supply Three-phase 3 x 230 / 400 V AC ± 5 %, 50 Hz...60 Hz
Single-phase 1 x 230 V ± 5%, 50 Hz...60 Hz
Power max. at 3 x 400 V AC, max. 3 kW
Control supply via L1, L2 400 V AC or 230 V AC + - 10 %, 50 Hz...60 Hz,
voltage changing with bridge to 3- pole terminal,
safety fuse F1 (1,6 A t)
External supply fuse 10 A delayed
Permitted Load ca. 40 V A (without motor and ext. 230 V)
External supply 1 230 V via L1 and N, safety fuse F1 (1,6 A t)
External supply 2 24 V DC uncontrolled, max. Load 1000 mA,
Protected via electronic fuse
Inputs 24 V DC / typ. 10 mA
signal length must be more than 100 ms
Relay output If inductive loads are to be switched (e.g. other relays)
those have to be protected with free-wheeling Diodes
contact load at 230 V max. 1 A
Trac light contacts LED - bulb 230 V
or
Normal bulb 230V shock resistant max. 40 W
Temperature Working: -10 °C...... +50 °C
Storage: +0 °C......+50 °C
Humidity: To 93 % not condensing
Vibration: Vibration free mounting, e.g. on at built wall
Protection class IP 54 (CEE Plug), IP 65 available
