GFA TS 981 - Maintenance Cycle Counter; Memory Check

Page 25
MEMORY CHECK
Press
selector
Info Cycle counter
7- digit
Last 2 faults would be alternately displayed.
Program version will be displayed
Displayed
Info last 2 faults
Press
selector
Info Program changes
7- digit
Info Program version
M HT ZT T H Z E
Press
selector
Press
selector
M HT ZT T H Z E
The cycles would be displayed as follow.
M = 1.000.000 H = 100
HT = 100.000 Z = 10
ZT = 10.000 E = 1
T = 1.000
The Number of program changes would be dis-
played as follow.
M = 1.000.000 H = 100
HT = 100.000 Z = 10
ZT = 10.000 E = 1
T = 1.000
2. Chose program and
conrm
CONTROL PROGRAMMING
01-99 correspond from 1.000 up to
99.000 Count down cycles
Counter adjustment
Display appears „CS“ and adjusted
number of cycles
Changing to Hold-to-run display appears „CS“ and
adjusted number of cycles
Changing to Hold-to-run same as „.2“ reset to
about 500 cycles possible, press 3 s Stop – Button
Reaction when
reaching 0
Maintenance cycle counter
3. Adjustment
2. Chose program and
conrm
Press
selector
Press
selector
4. Memorise
Display appears „CS“ and adjusted number
of cycles and Relay contact is activated
0.0
8.5
8.6
.4
.2
. 1
.3
9. 1
9.2
9.3
9.4
