GFA TS 981 - Safety Functions

Page 21
Functions
CONTROL PROGRAMMING
4.
Memorise 3. Adjustment
2. Choose program and
conrm
Press
selector
OFF
Function Relay 1
only available with
Menu item 1.7
Switch contact impulse: 1s
Switch contact continuous
Switch contact impulse: 1s
by open - commands
Function Relay 2
only available with
Menu item 1.8
Functions Intermediate
Position
Intermediate position terminal input via
X7 / X17 and Three Push Button X5 /X15
Intermediate position terminal input via
X7 / X17; and fully open via Three Push
Button X5 / X15
Intermediate position terminal input via
X7 / X17; and fully open via Three Push
Button X5 / X15
Press
selector
Safety functions
Door overload monitor
OFF
Sensitive
Insensitive
Press
selector
Extended switch contact similar NES
cam
Light curtain testing at final Open position
before closing
External brake supply
ATTENTION!
.2 and .3 not applicable with
tra󰀩c light function and
inerlocking function.
Menu item 6.1 to .0
Menu item 7.1 to .0
Smoke and heat extraction
.2
.3
.4
.5
.0
. 1
2.7
2.8
3. 1
.7
.8
.2
.3
. 1
2.9
.2
.0
. 1
