INSTALLATION ADVICE
After the ELEKTROMATEN
®
is tted we recommend the following procedure to rapidly reach
a fully functioning door.
• Installation Enclosure installation page 8
• Installation Wiring the Drive to the Control page 8
• Check Mains supply page 9
• Check Phase rotation page 10
• Programming Rapid limit adjustment page 11
The door is ready to work in Hold-to-run mode.
• Installation Safety devices page 14, 27
• Programming Door functions page 18
The door is ready to work in automatic mode.
Check connection of external devices e.g. push button etc.
Overview to connect external devices see diagram (page 14-17).
After the devices are connected the programming of the control panel must be nalised.
(page 18).
