GFA TS 981 - Ceiling Pull Switch; Radio Control X7; X17; Key Switch - Intermediate Stop X8

Page 34
FUNCTION DESCRIPTION
Shutter position Shutter operation
Shutter closed Shutter travels to fully OPEN*-position
Shutter moving upwards No reaction
Shutter open Shutter moves to fully closed position
Shutter intermediate position open Shutter moves to fully closed position
Shutter moving downwards Shutter will STOP and moves BACK UP to nal open Position*)
Ceiling pull switch / Radio control X7 / X17
It is possible to connect a ceiling pull switch or a radio receiver.
The radio receiver's switching contact must be potential free. Menu item 2.6: Several types
of commands can be adjusted. With each command (impulse) the shutter operates in the
following sequences.
With each command (contact) the shutter operates in the following sequence:
*) or to the intermediate stop position when the key switch is in the ON position
Intermediate stop can be activated / de-activated by connecting a key switch (latching ON-
OFF). The intermediate shutter position „ PART OPEN“ is only in e󰀨ect in the upwards direction
and is the new open position.
In Menu item 1.6 the position can be adjusted. This is the new nal position.
By turning the key switch to the OFF position, the shutter works in standard mode.
Menu item 2.9 Adjustment of these several functions.
To get adjusted function working the terminals X8.1 / X8.2 need to be bypassed.
Key switch – intermediate stop X8
Shutter position Shutter operation
Shutter closed Shutter moves to fully open* or intermediate position
Shutter moving upwards Door closed
Shutter open Shutter moves to fully closed position
Shutter intermediate position open Shutter moves to fully closed position
Shutter somewhere in between Shutter moves in opposite direction
position
Shutter moving downwards Door closed
*) or to the intermediate stop position when the key switch is in the ON position
Command 1: Without STOP
Command 2: With STOP
Command 3: OPEN
With each impulse the door travels to the nal open position
Important note!
To ensure error free function of the panel, the terminal X8 must not be
used without intermediate stop adjustment.
