Page 33
FUNCTION DESCRIPTION
Reaction of automatic closing to photo cell / light curtain: Menu item 2.4:
Function Reaction of automatic closing to photo cell / light curtain
„.0“ No function
„.1“ Stopping automatic The door closes 3 seconds after the photo cell is re-made
closing
„.2“ Vehicle recognition As above „.1“ but the photo cell must be obstructed for more
than 1.5 seconds.No function if the photo cell is obstructed for
less than 1.5 seconds
Photo cell ignore function: Menu item 3.2:
Warning!
Presence detection „stop and re-open“ is disabled in the Teach-in mode
In the Teach-in mode, the door must be fully opened and closed twice. The photo cell must be
interrupted twice at the same door position. The Teach-in mode then terminates. The photo
cell does not function below this stored door position.
Important note!
If the teaching-in is not successful, open and close the door again until the
photo cell has been interrupted at the same door position twice.
Function Photo cell function disabled
„.0“ O
„.1“ On
Teach-in mode display
Upon exiting the programming
When the light beam is interrupted for the rst time (1
st
open / close cycle)
After the second interruption of the light beam, 2
nd
open / close cycle and
must be at the same door position as the interruption in the 1
st
cycle, at the
nal limit CLOSE position
Set Menu item 3.2 = „.1“ and then exit programming to activate the „photo cell ignore“ teach-in
mode.
2.4
1.4
1 . 1
