SECTION 3 - REMOVING COMPONENTS

To remove the Hub Interface PCB (HIP) assembly (if existing in the unit), proceed as follows:

1 Disconnect all the cables from the HIP.

2 Remove the three 7-mm nuts underneath the HIP assembly.

Note: Retain the nuts for reuse.

Figure 7: Removing HIP Assembly

(i)

(iii)

(ii)

Nut (3X)

HIP Assembly

Auxiliary Power Supply
