MDE-5222F
Purpose
This manual provides instructions:
• To install a 5.7- or 10.4-inch Color Screen FlexPay™
IV CRIND® Retrofit Kit in an Encore® 300/500 unit
(with or without CRIND). The FlexPay IV CRIND provides a secure payment platform that is
EMV®-certified and Payment Card Industry PIN Entry Device (PCI-PED)-certified.
• To install an Auxiliary Feature Processor [AFP (M13124A001)], or a Dispenser Communication Module
[DCM (M14576A001)]2/DCM2.1/DCM2.2.
DCM2 board is a superset of the AFP. It contains the dispenser side of the high-speed solution and has the
ability to mount the Secure System on Module (SSoM). SSoM is a board that provides the Insite360™ Encore
functionality.
Intended Users
This manual is intended for Gilbarco®-trained and certified Authorized Service Contractors (ASCs).
Required Tools
• Phillips® and Flat-blade Screwdrivers
• 1/4-inch Socket Set (Nut Driver)
• 7- and 8-mm Socket (Nut Driver or Socket Set)
• Diagonal Cutters
• Needle Nose Pliers
• T15 Torx Driver
• Torque Wrench for Card Reader Nuts, 10-12 inch-lbs
• Metal Shears
• Putty Knife or Scraping Tool (if required)
• Gloves
