SECTION 6 - APPENDICES

MDE-5222F

Appendix B: Block Diagrams

Figure 5: Cable Block Diagram for FlexPay IV CRIND - 1

Note: This diagram shows an installation with AFP without Applause Media System.



For DCM2, Applause Media System, or intercom details, see “DCM2 Board (M14576A001)”



on page 20, “DCM2.2 Assembly” on page 26, and



“M09751A002 Intercom Option” on page 50.
