SECTION 4 - INSTALLATION
4
MDE-5222F
Applause Media System Cable Connections
Figure 12 shows the cable connections for Applause Media System.
Figure 12: Cable Connections
M14338
Route along 
T-rail through
door hinge to
UPM.
GSoM, mounted to AFP or DCM2.
Side A GSoM is mounted to the
left, side B is to the right.
UPM on Door
PIP3 mounted behind display on door.
If no intercom board, connects to speaker.
With intercom board, connects to J504 on
M10590A004 Cable
M14425 Route
along T-rail
through door
hinge to UPM.
The audio signal
is intercepted by
J504 on
M10590A004
Cable and
intercom board,
if present.
