DCM2.2 LED Indicators
Check the following LED indicators after DCM2.2 is powered ON.
Function Color Control
CCP Power_Good LED Green Driven when 2.5 V, 3.3 V and 5 V are present
HomePlug Power LED Green ON: Power ready
Flashing: Loading firmware
OFF: Power not ready
HomePlug Status LED Green ON: HomePlug link detected
Flashing: TX or RX activity
OFF: HomePlug link not detected
Two-wire Orange Flashing: TX and RX (two-wire) detected
ON: RX is solid and TX is OFF if there is an Open
connectio
n. Wire is not connected.
OFF: No communication. Both TX and RX are OFF
SSoM Activity Green ON: SSoM is detected
Flashing: After SSoM registered
Router Enable Green ON: When the SSoM is installed and has Cloud
connectivity
P304 ETH Link/Act Orange ON: When we use CAT5 configuration
OFF: When we use HomePlug
DCM2.2 Jumpers
The following table lists the status and functions of jumpers:
Connector ON OFF Function
J3 X High-speed connection active. P304
A/B disabled.
X High-speed connection inactive. P304A
and P304B connects to Category
5 (CAT5) running through the conduit for high speed connection (if used).
J4 X Unit is connected to a Passport POS MOC
X Unit is connected to a third party POS (Generic)
J5 X VLAN is enabled
X VLAN is disabled
J6 B Install the jumper on the B position for the 45 mA Current loop
RJ-45
P304A/B Ethernet connection to the back room. P304B
is the
optional discreet wire connection.
J305C Ethernet connection to UPM A
J310A Ethernet connection to UX300 A
J310B Ethernet connection to UPM B
J303B Ethernet connection to UX300 B
J303A Laptop Service port 1
J310A Laptop Service port 2
DCM2 Connector Port Number Function
