The ZMODEM is a new connection to PCN (laptop port) that is required to
perform many remote PCN functions. Ensure that the ZMODEM cable is
reconnected after performing any laptop tasks on PCN or after part
replacement. Additionally, after part replacement (for example, PCN or
CRIND replacement), ensure that the software on the new component
meets minimum requirements.
IMPORTANT INFORMATION
MDE-5222F
26
DCM2.2 Assembly
The DCM2.2 Assembly (M15737A001) mounts in the same location as the DCM2.1 Assembly
(M15399A001). Use the M15241A002 Cable in order to interface with PCN with the latest DCM2.2
Assembly. The M15341A101 CCP Board provides the same functionality as the AFP, along with a high-speed
data connection for the Applause Media System (GSoMs), Insite360 Encore, and future EMV applications.
DCM2.2 has the dedicated high-speed (P333) connection from the backroom, as well as a new Light Emitting
Diode (LED) that monitors the SSoM router functionality. Refer to “DCM2.2 LED Indicators” on page 28.
To install DCM2.2 assembly, proceed as follows:
1 Transfer the GSoMs removed in step 3 on page 16 to the new DCM2.2 assembly.
Note: Ensure that you transfer the GSoMs to the correct side (side A to side A; side B to side B).
2 Mount the DCM2.2 assembly onto the mounting bracket using the three 7-mm nuts removed in step 2
on page 16.
3 Connect all the applicable Cables to the DCM2.2 assembly as shown in Figure 11 on page 27.
4 Connect the M15241A002 ZMODEM Cable to P1111 on the PCN, to P315 [also labeled as ZMODEM
Pump on the DCM2.2 (Encore 500 only)].
