Gill Instruments WindObserver II User Manual

Gill Instruments Ltd
_____________________________________________________________________________________________________________
________________________________________________________________________________________________
WindObserver II Page 31 Issue 18
Doc. No. 1390-PS-0004 January 2009
8.8. ASCII message format (UV, Polar and Tunnel)
ASCII UV format
U axis wind speed V axis wind speed Units
<STX>A,+000.04,-000.02,M,+345.01,+022.36,00,<ETX>25
Start of
string
Unit
identification
Speed of
sound
Temperature Status End of
string
Check
sum
Where
U axis wind speed
In increments of 0.01 units (±UUU.UU)
V axis wind speed
In increments of 0.01 units (±VVV.VV)
Value Units
Units
M Metres per second (m/s)
N Knots (knots)
P Miles per hour (MPH)
K Kilometres per hour (kph)
F Feet per minute (fpm)
Start of string
ASCII value 2
Unit identification
Letter A – Z (default A)
Speed of sound
In metres per second (if enabled)
Temperature
Sonic temperature in degrees C (if enabled)
Status Value Status
0 OK
60 Heating enabled and OK if enabled
Any other value Warning or fault condition
- see Section 10.5
End of string
ASCII value 3
Check sum
Exclusive OR of all characters between Start of String
and End of String reported as ASCII hex.
