WindObserver II Page 42 Issue 18

Doc. No. 1390-PS-0004 January 2009

Kx – NMEA Settings

Setting Configuration code

NMEA string “IIMWV” K1

NMEA string “WIMWV”

Lx - ASCII Message Terminator

Setting Configuration code

CR LF L1

Mx to Mxx - Message Format

Output format Configuration code

ASCII UV Continuous

ASCII Polar Continuous M2

ASCII UV Polled (tri-state) *

ASCII Polar Polled (tri-state) *

NMEA Continuous

Binary Tunnel Continuous

Binary UV Continuous

Binary Polar Continuous

ASCII Tunnel Continuous

M12

ASCII Tunnel Polled (tri-state) *

M13

* If units are to be networked, they MUST be given unique Unit Identifiers

Nx - Node Address

Item Options Command

Node Address

A… -(A to Z)

N<A>

If used in a multi-drop system then it is recommended that ID’s A to F and K, M, N and P

are not used, as these characters can be present in the data string.
