Ox – ASCII Output Format (Output String Padding)
Setting Configuration code
Comma Separated Variable (CSV)
O1
Fixed Field
O2
Example data strings:-
POLAR NMEA
CSV data changing to error status code
condition.
CSV data changing to error status code
condition.
A,235,000.77,M,00,0A $IIMWV,191,R,000.55,M,A*19
A,,,M,04,24 $IIMWV,,R,,M,V*29
Fixed Field data changing to error status
code condition.
Fixed Field data changing to error status
code condition.
A,266,000.73,M,00,08 $IIMWV,191,R,000.55,M,A*19
A,999,999.99,M,04,0A $IIMWV,999,R,999.99,M,V*07
Px - Output Rate
Outputs per second 1
2 4 5 8 10
Configuration code
P1
P3 P2 P4 P5 P6
Q- Measurement Mode
See Section 9.2.
Tx - Analogue Output Voltage or Current settings (if fitted)
Setting Configuration code
Voltage (0 to 5V) T1
Voltage (–2.5V to +2.5V)
T2
Current (4-20mA)
T3
Ux – Digital Output Units
Units metres/sec
(m/s)
knots
(knots)
miles / hour
(MPH)
kilometre/hour
(kph)
feet / minute
(fpm)
Configuration
code
U1
U2 U3 U4 U5
Vx- Vertical Output Padding
Setting Configuration code
Disable vertical output padding V1
Enable vertical output padding
V2
