Adjustment
screw
Locking key
Compression cam
Trigger key
NOTE
The images on this page are shown without safety covers for
clarity.
Mobile
retaining bar
Fixed
bar
Fixed
bar
16
PUMP HEAD WITH SAFETY COVER | MINIPULS® 3 PERISTALTIC PUMP
PUMP HEAD WITH SAFETY COVER
