Install Pump Head
1 Place the two mounting screws (partnumber 4011564204,
supplied in the accessory kit) through the pump head.
2 Install the pump head on top of the speed control module in the
desired position; four are possible. Do not position it with the
drain tube to the front.
3 Turn the roller shaft so that the slot at the bottom of the shaft
aligns with the tab of the rubber coupler in the speed control
module. Turning the shaft gently back and forth can help the user
to engage it with the tab. When these two parts are properly
engaged, the base of the pump head rests on top of the speed
control module.
4 Slide the pump head so that the two screws fall into their inserts
and then tighten the screws, but do not over-tighten.
25
MINIPULS® 3 PERISTALTIC PUMP | USER'S GUIDE
INSTALL OR CHANGE THE PUMP HEAD
