Open Pump Head
1 Unlock each channel of the head by pressing the trigger key
towards the roller barrel.
2 Swing the compression cam out.
Trigger
key
Compression
cam
Safety cover
24
INSTALL OR CHANGE THE PUMP HEAD | MINIPULS® 3 PERISTALTIC PUMP
INSTALL OR CHANGE THE PUMP HEAD
