Technical Specifications
Description Specification
Operating Temperature
4–40°C
No warm-up time is required before operation
Position
Upright only (vertical ±5°).
Head Speed
0.01 to 48 rpm
Torque
Greater than 3 Nm at any speed below 25 rpm, at or above the nominal voltage (24V DC)
Motor Speed Stability
0.5% for any variation, torque, or temperature
Continuous Speed
Adjustment
From 0 to 48 rpm by 0.01 increments up to 9.99 rpm, above 9.99 rpm by 0.1 increments
Flow Rate Range
Maximum: MP model 40 mL/min (1.8 L/h, 4 mm tubing), HF model 250 mL/min (15 L/h,
8 mm tubing)
Minimum: 0.3 µL/min (0.25 mm tubing)
Maximum Back Pressure
0.5 MPa (72.5 psi) for MP models, 0.3 MPa (43.5 psi) for HF models
Peristaltic Tubing
Diameter:
0.25 to 4 mm (ID) for MP models, 2 to 8 mm (ID) for HF models
Power Requirements
(External Power Supply)
Voltage Input
100–240V AC, 50 to 60 Hz
Voltage Output
24V DC, 1.7A, 41W
Dimensions without
pump heads (W x D x H):
15.0 x 17.5 x 18.5 cm (5.9 x 6.9 x 7.3 in.)
Humidity
Up to 80%
Weight
2.5 kg (5.5 lbs.)
Altitude
Up to 2000 m
72
TECHNICAL SPECIFICATIONS | MINIPULS® 3 PERISTALTIC PUMP
