Pump Speed (Analog Input)
A DC voltage (0–5V) or a resistance (resistor or potentiometer)
between pin 7 and ground can be used to change the rotation speed
as described below.
VOLTAGE CONTROL
Effective Speed =
(Selected Speed x Applied Voltage)/5 Volts
The Applied Voltage is expressed in Volts.
The Selected Speed is displayed before the Start/Stop input is
activated.
The Effective Speed is displayed after the Start/Stop input is
activated.
RESISTANCE CONTROL
Effective Speed =
(Reference Speed x Resistance)/(Resistance + 68)
The resistance is expressed in kOhms.
The Reference Speed is obtained with an infinite resistance (open
circuit).
Control by Gilson Devices
Please refer to the respective technical manuals. For more details,
please contact your local Gilson representative.
GSIOC Control
Gilson systems feature a two-way communication interface between
the computer and most Gilson instruments. Communication occurs
along the Gilson Serial Input Output Channel (GSIOC).
55
MINIPULS® 3 PERISTALTIC PUMP | USER'S GUIDE
ELECTRICAL CONTACT CONTROL
