Coupling Kits
These are used to connect the peristaltic tubing to PTFE tubing
having flanged ends, or to connect the peristaltic tubing to Low
Pressure Liquid Chromatography (LPLC) systems. The coupling kit
consists of a connection screw and a cone. The figure shows a typical
connection to an LPLC system.
A Tefzel® connector (partnumber495051) is available for connecting
flexible tubing (ID 1 to 3 mm) to tubing connection screws at Gilson
chromatography column outlets.
Couplers
Two types of couplers
are available.
F1410050 consists of a
set of five PVDF couplers
for linking two standard
Gilson connection screws
(1/4"-28 TPI).
495036 consists of
one Teflon® coupler
for linking connection
screws of different sizes
(1/4"-28 TPI to 10 mm
standard thread).
40
